With a redesigned rim profile the new ARC Offset rims utilize an asymmetrical design to optimize spoke tension balance wheel durability and wheel stiffness. New 6069 Alloy provides a superior strength to weight ratio over our previous generation of ARC significantly improving toughness. And now with our new 30mm wide Heavy Duty rim at 22mm deep we have a rim size and width option for every tyre and every riding style. Our tubeless ready bead and offest design mean these rims are ready to hit any trail with confidence.
Features
- Tubeless ready strong tyre retention bead.
- Sizes from 25mm to 40mm internal width.
Specification
| 27.5" | 29" |
| Rim Weight | 25mm - 418g 30mm - 484g 35mm - 520g 40mm - 560g | 25mm - 445g 30mm - 525g 35mm - 553g 40mm - 596g |
| Finish | Brushed Black Anodise / Vinyl Decals | Brushed Black Anodise / Vinyl Decals |
| Type | Tubeless Ready Clincher (Tape and valve kit sold seperately) | Tubeless Ready Clincher (Tape and valve kit sold seperately) |
| Rim Material | 6069 High Strength Alloy | 6069 High Strength Alloy |
| Rim Depth | 20mm | 20mm |
| Rim Offset | 4.5mm | 4.5mm |
| Internal Rim Width | 25mm 27mm 30mm 35mm 40mm | 25mm 27mm 30mm 35mm 40mm |
| External Rim Width | 29mm 31mm 34mm 39mm 44mm | 29mm 31mm 34mm 39mm 44mm |
| Spoke Holes | 28 or 32 Hole | 28 or 32 Hole |
| Rim ERD | 562mm (25-40mm) | 600mm (25-40mm) |
| Max Spoke Tension | 122KGF / 1200N | 122KGF / 1200N |
